Lasertronic
Salient Features
- Yarn Built-up through Laser Sensor
- Extremely robust separate warping and beaming structure.
- Movable beaming structure on both side.
- Extremely effective air cooled hydraulic disc break.
- Constant beaming tension with beam oscillation function.
- Three servo system for warp table traverse motion, warp table cross. Motion and machine head stock motion in synchronization with each other.
- Ball screw for high precision warping.
- Linear guide for under carriage movement.
- Kick Back type Feeler Roller for Compact Beam
- Programmable Leasing Device
- Section Tension Control
- Reverse/Forward Drum Rotation
- Remote Diagnosis - online support from our Service head Office
| Working Width | : | 1800 mm to 4200 mm |
| Beam Flange Diameter | : | 800 - 1250 mm |
| Cone Angle | : | 7° / 8.5° / 10.5° |
| Drum Circumference | : | 3140 mm |
| Warping Speed | : | 0 - 800 mts/min |
| Beaming Speed | : | 0 - 150 mts/min (higher on request) |
| Beaming Tension | : | 0 - 450 Kg (higher on request) |
